Options: Air Pump / Gear Pump / Mixture Agitator /Stainless Steel Handle / Automatic Rebound Valve Body
Certification:
Air cooled
Minimum Clearance should be 300mm on left,right, and rear for assuring adequate air flow
Electrical
One dedicated electrical connection is required. Check with local electrician for cord and receptacle specifications if 50 Hz or 60 Hz Equipment is desired
Customization
Product customization may be available upon request
Regulates the entire refrigeration process and maintains consistent product viscosity, adjustable through modifying viscosity between level 1 and level 8 on the front panel.
Shuts down for self protection when motor overload or compressor overheat occurs due to power surge or abnormal voltage from power supply.
The low liquid alarm will sound when the hopper is lack of ice cream mix.
The number of ice creams dispensed is displayed on the front panel each time the discharge handle is pressed.
The machine automatically enters standby mode after two hours of inactivity and will resumes normal operation after any keys or handles are pressed.
The ice cream machine can apply to broad voltage range from 198V to 238V.
Weight | Ibs. | Kgs. | |
Net |
396 |
180 |
|
Total |
451 |
205 |
|
Dimensions | in. | mm. | |
Width |
21.9 |
555 | |
Depth |
29.0 |
735 | |
Height |
52.0 |
1320 | |
Electrical | Maximum Fuze Size |
Minimum Ampacity |
Poles(P)Wires(W) |
220-240/50/1 |
35 | 18 | 2P 3W |
220-240/60/1 |
35 | 18 | 2P 3W |
Model |
Power |
OP138CS |
2500W |
Flavors |
Main Compressor |
2+1 mixed |
1.25HP |
Production Capacity |
Cooling System |
38L/H |
Air Cooled |
Mix Hopper |
Refrigerant |
2*12L |
R404A |
Cylinder |
Options |
2*2L |
Air Pump / Gear Pump / Mixture Agitator / Stainless Steel Handle / Automatic Rebound Valve Body |
